Contact Us

, Posted in

BORCH TECHNOLOGY
           DARKNESS IS NOTHING



  • E-mail:  borchtech@gmail.com, coolas_sam@hotmail.com

  • Phone:  021-4325170 / 4325171

  • Fax:  021-4325172

  • Address:  Suite No. 407, 4th Floor, Anum Blessing K.C.H.S.U Society                                                                         Sharah-e-faisal Karachi.

About Us

, Posted in



Borch Technology is a privately held Company was founded in Karachi in 1995, have over 50+employees with branch offices in Lahore and Islamabad. We have always adapted to meet the challenges of the changing era.


Borch Technology is a leading supplier of Security Cameras, & DVR Security equipments. We offer complete security solutions that are becoming an absolute necessity for every business, home and industry.


From cameras to DVR equipments, we offer high quality video surveillance products at very competitive prices. Chain stores, commercial customers and homeowners approve our top - notch services and innovation product lines and appreciate our outstanding efforts at handling their surveillance business.


We assure to deliver the special care and attention that is required towards improving your system just Looking forward to a very effective and long lasting relation ship with a desire to serve you, please don't hesitate to contact us.

Model : BS 816 - 16 Channel DVR

, Posted in , ,


Complete Information

Model : BS 816 - 16 Channel DVR

Technical Standards


1,Video Parameters:
Video Input: composite video input PAL(25 fps) NTSC(30 fps) (BNC, 1Vp-p, 75Ohm)
Video Output:1 channel composite video output (BNC, 1Vp-p,75Ohm) PAL (625 line/frame) NTSC (525 line/frame)
1 VGA output(Frequency:60 Hz, resolution: 800*600, 1024X768, 1280X768, 1360X768)
2,Audio Parameters:
Audio input: 16 channels audio input(BNC, 10KOhm, Vp-p=2.0V LINE)
Audio output: 1 channel audio output(BNC, 10KOhm, Vp-p=2.0V LINE)
Voice-chat: Input(BNC, 10KOhm, Vp-p=2.0V LINE in/ 50mV MIC in)
Output(BNC, 10KOhm, Vp-p=2.0V LINE£©N/A

3,Video Compression: H.264
CIF:PAL(352X288) 25 fps/ch;NTSC(352X240)30 fps/ch
4,Audio Compression: G.711/G.722, Audio sampling rate 8K/16K sample/ sec., 16 bit/sample
5,Operation System: Real Time Operation System (RTOS)
6,HDD interface: 2 SATA interfaces,support 48bit LBA working mode
7,Alarm interface:
Alarm input: Support open normally and close normally; support 16 channels alarm input
Alarm output: 2 channels alarm output (delay opened circuit, relay output)
8,I/O interface: RS485 interface supports network transparent channel connection and serial port control keyboard.
9,Operation mode: multi-functional IR remote control, PS/2 mouse, serial port control keyboard.
10,Backup interface: support data backup function
11,Network port: RJ 45 10M/100M Ethernet Interface
12,Power supply: 220+/-30% V,50+/-3% HZ  110+/-20% V,60+/-3% HZ optional
13,Dimension: 405 X 310 X 55 (Length * Width * High, mm.)

Model : BS 808 - 8 Channel DVR

, Posted in , ,


Complete Information

Model : BS 808 - 8 Channel DVR

Technical Standards


1, Video Parameters:
Video Input: composite video input PAL(25 fps) NTSC(30 fps) (BNC, 1Vp-p, 75Ohm)
Video Output: 1 channel composite video output: (BNC, 1Vp-p,75Ohm)PAL(625 line/frame) NTSC(525 line/frame)
1 VGA output(Frequency 60 Hz, resolution:800X600,1024X768,1280X768,1360X768)
2, Audio Parameters:
Audio input:N/A
Audio output:N/A
Voice-chat: Input (3.5MM MIC in, 10KOhm, Vp-p=2.0V LINE in/ 50mV MIC in)
Output (BNC, 10KOhm, Vp-p=2.0V LINE)
3, Video Compression: H.264
CIF:PAL(352X288)25 fps/ch;NTSC(352X240)30 fps/ch
4, Audio Compression: G.711/G.722, Audio sampling rate 8K/16K sample/ sec., 16 bit/sample
5, Operation System: Real Time Operation System (RTOS)
6, HDD interface: 2 SATA interfaces,support 48bit LBA working mode
7, Alarm interface:
Alarm input: Support open normally and close normally; support 8 channels alarm input
Alarm output: 2 channels alarm output (delay opened circuit, relay output)
8, I/O interface: RS485 interface supports network transparent channel connection and serial port control keyboard.
9, Operation mode: multi-functional IR remote control, PS/2 mouse, serial port control keyboard
10, Backup interface: support data backup function
11, Network port: RJ 45 10M/100M Ethernet Interface
12, Power supply: 220+/-30% V,50+/-3% HZ  110+/-20% V,60+/-3% HZ optional
13, Dimension: HB7004 325 X 220 X 55,HB7008&HB7016 405 X 310 X 55 (Length * Width * High, mm.)

Model : BS 710 - 4 Channel DVR

, Posted in , ,


Complete Information

Model : BS 710 - 4 Channel DVR

Technical Standards


1,Video Parameters
Video Input: composite video input PAL(25 fps) NTSC(30 fps) (BNC, 1Vp-p, 75Ohm)
Video Output:1 channel composite video output (BNC, 1Vp-p,75Ohm) PAL (625 line/frame) NTSC (525 line/frame)
1 VGA output(Frequency:60 Hz, resolution: 800*600, 1024X768, 1280X768, 1360X768)
2,Audio Parameters
Audio input: 4 channels audio input(BNC, 10KOhm, Vp-p=2.0V LINE)
Audio output: 1 channel audio output(BNC, 10KOhm, Vp-p=2.0V LINE)
Voice-chat: Input(BNC, 10KOhm, Vp-p=2.0V LINE in/ 50mV MIC in)
Output(BNC, 10KOhm, Vp-p=2.0V LINE)

3,Video Compression: H.264
CIF:PAL(352X288) 25 fps/ch;NTSC(352X240)30 fps/ch
4,Audio Compression: G.711/G.722, Audio sampling rate 8K/16K sample/ sec., 16 bit/sample
5,Operation System: Real Time Operation System (RTOS)
6,HDD interface: 1 SATA interfaces,support 48bit LBA working mode
7,Alarm interface:
Alarm input: Support open normally and close normally; support 4 channels alarm input
Alarm output: 2 channels alarm output (delay opened circuit, relay output)
8,I/O interface: RS485 interface supports network transparent channel connection and serial port control keyboard.
9,Operation mode: multi-functional IR remote control, PS/2 mouse, serial port control keyboard
10,Backup interface: support data backup function
11,Network port: RJ 45 10M/100M Ethernet Interface
12,Power supply: 220+/-30% V,50+/-3% HZ  110+/-20% V,60+/-3% HZ optional
13,Dimension: 325 X 220 X 55(Length * Width * High, mm.)
